Smart Cassette 4PON GPON OLT
Smart Cassette GPON OLT 4PON

  Request price     Contact us

INFORMATION

Product Overview

4 PON is a small-capacity cassette GPON OLT, meeting the requirements of ITU-T G.984 and relative standards of China Telecom/Unicom GPON, with super GPON access capacity, carrier-class reliability and the complete security function. It can satisfy long-distance optical fiber access requirement on account of its excellent management, maintenance and monitoring capability, abundant service features and flexible network mode.GPON OLT can be used with NGBNVIEW network management system so as to provide users with the comprehensive access and perfect solution.

GPON OLT 4 PON provides 4 * downlink GPON port, 4 *GE combo port and 2* 10G SFP+ port. The height is only 1U for easy installation and space saving. They are suitable for Broadcast three in one, video surveillance network, enterprise LAN, Internet of Things, etc.



Product Specification:

Item

GPON OLT 4PON

Switching Capacity

63Gbps

Forwarding Capacity(Ipv4/Ipv6)

46.8Mpps

Service Port

4*PON port, 4*GE COMBO port, 2*10GE SFP+ port

Redundancy Design

Dual power supply

Support double AC input, double DC input and AC+DC input

Power Supply

AC: input 90264V 47/63Hz;

DC: input -36V-72V;

Power Consumption

50W

Dimensions (Width x Depth x Height)

437mm×44mm×280mm

Weight (Full-Loaded)

≤4KG

Environmental Requirements

Working temperature: -10°C55°C

Storage temperature: -40°C70°C

         Relative humidity: 10%90%, non-condensing



Product Features:

                        Item

                                        GPON OLT 4PON

PON Features



ITU-TG.984.x;

SN/Password/SN+ Password/LOID/LOID Password/LOID+LOID Password authentication modes;

DBA algorithm, and the particle is for 64Kbit/s;

Standard OMCI management function;

ONU batch software upgrade;

PON port optical parameter detection;

L2 Features

MAC

MAC Black Hole;

Port MAC Limit;

32K MAC (packet exchange chip cache 2MB );

VLAN

4K VLAN entries;

Port-based VLAN classification;

Uplink static QinQ and flexible QinQ(Stack VLAN);

Uplink VLAN Swap and VLAN Remark;

GVRP;

Spanning Tree

STP/RSTP/MSTP;

Remote loop detecting;

Port

Bi-directional bandwidth control;

Support static and LACP dynamic port aggregation;

Port mirroring;

Security

Features

User’s Security

Anti-ARP-spoofing;

Anti-ARP-flooding;

IP Source Guard for creating IP+ VLAN+ MAC+ Port binding;

Port Isolation;

MAC address binding to the port and MAC address filtering;

IEEE 802.1x and AAA/Radius authentication;

Device Security

Support the control layer to prevent a variety of DOS attacks and virus attacks against the CPU;

SSHv2 Secure Shell;

SNMP v3 encrypted management;

Login Security IP via Telnet;

Hierarchical management and password protection of users;

Network Security

User-based MAC and ARP traffic examination;

Restrict ARP traffic of each user and force-out user with abnormal ARP traffic;

Dynamic ARP table-based binding;

IP+ VLAN+ MAC+ Port binding;

L2 to L7 ACL flow filtration mechanism on the 80 bytes of the head of user-defined packet;

Port-based broadcast/multicast suppression and auto-shutdown risk port;

URPF to prevent IP address counterfeit and attack;

DHCP Option82 and PPPoE+ upload user’s physical location Plaintext authentication of OSPF, RIPv2 and BGPv4 packets and MD5cryptograph authentication;

Service Features



ACL

Standard and extended ACL;

Time Range ACL;

Flow classification and flow definition based on source/destination MAC address, VLAN, 802.1p, ToS, DiffServ, source/destination IP(IPv4/IPv6) address, TCP/UDP port number, protocol type, etc;

packet filtration of L2L7 deep to 80 bytes of IP packet head;

QoS

Rate-limit to packet sending/receiving speed of port or self-defined flow and provide general flow monitor and two-speed tri-color monitor of self-defined flow;

CAR(Committed Access Rate),Traffic Shaping and flow statistics;

Packet mirror and redirection of interface and self-defined flow;

Supports priority marking of ports or custom flows and provides 802.1p, DSCP-priority Remark capability;

Super queue scheduler based on port or self-defined flow. Each port/flow supports 48 priority queues and scheduler of SP, WRR and SP+WRR;

Congestion Avoidance Mechanism, including Tail-Drop and WRED;

IPv4

ARP Proxy;

DHCP Relay;

DHCP Server;

Static Routing;

RIPv1/v2;

OSPFv2/V3;

Equal-cost multi-path routing;

Policy-based routing;

Routing policy

IPv6

ICMPv6;

ICMPv6 Redirection;

DHCPv6;

ACLv6;

IPv6 and IPv4 dual stack;

Multicast

IGMPv1/v2/v3;

IGMPv1/v2/v3 Snooping;

IGMP Filter;

MVR and cross VLAN multicast copy;

IGMP Fast leave;

IGMP Proxy;

PIM-SM/PIM-DM/PIM-SSM;

MLDv2/MLDv2 Snooping;

Reliability

Loop Protection

ERRP or ERPS;

Loopback-detection;

Link Protection

FlexLink (recover-time <50ms);

RSTP/MSTP (recover-time <1s);

LACP (recover-time <10ms);

BFD;

Device Protection

VRRP host backup;

1+1 power hot backup;

Maintenance

Network Maintenance

Port real-time, utilization and transmit/receive statistic based on TGLnet

RFC3176 sFlow analysis;

LLDP;

GPON OMCI;

Data Logging and RFC 3164 BSD syslog Protocol;

Ping and Traceroute;

Device Management

CLI, Console port, Telnet ;

SNMPv1/v2/v3;

RMON (Remote Monitoring)1,2,3,9 groups MIB;

NTP;

NGBNView network management;

Power Failure Alarm;




Ordering information
