24Cores Fiber Access Terminal Box
24Cores Fiber Access Terminal Box

  Request price     Contact us

INFORMATION

24Cores Fiber Access Terminal Box is able to hold up to 24 subscribers. It is used as a termination point for the feeder cable to connect with drop cable in FTTX network system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.

Features

  • Water-proof design with IP-65 Protection level.
  • Integrated with splice cassette and cable management rods. Manage fibers in a reasonable fiber radius condition.
  • Easy to maintain and extend the capacity. Fiber bend radius control more than 40mm.
  • Suitable for the fusion splice or mechanical splice. 1*8 Splitter or 1*16 Splitter can be installed as an option.
  • Efficient cable management.
  • 24 ports cable entrance for drop cable.

GF 23-24 plastic fiber distribution box parameters

1.1 Model: GF 23-24

1.2 Name: plastic fiber distribution box

1.3 Size: 340*265*115mm

1.4 Weight: 2KG

1.5 Material: ABS or PP

1.6 Number of cores: 24 cores

1.7 Color: Gray

1.8 Waterproof grade: IP65

1.9 Product pictures

Configuration

Material

Size

Max Capacity

Installation size

Weight

Color

PC +ABS

A*B*C(mm) 340*265*115

SC

24 Ports

LC

48 Ports

PLC 1x8(SC)

D*E(mm)

168*210



2kg



Light Gray





Ordering information
