INFORMATION
Overview:
BD-ONU-312H EPON ONU fully comply with IEEE802.3ah EPON standards. It is operative, manageable and maintainable at telecommunication level, and can provide high speed data service for customers. It has a PON uplink port that connects to office end apparatus through optical fiber.
BD-ONU-312H provide one 1000Base-T Gigabit Ethernet ports,one 100Base-T fast ethernet port and one CATV RF port. The ONU can support data,CATV, and ITV service, which is ideal FTTX application solution.
Technical Specification:
<!--[if !supportLists]-->í <!--[endif]-->Power adapter input：220V AC，50HZ
<!--[if !supportLists]-->í <!--[endif]-->System power supply: See the nameplate on the device
<!--[if !supportLists]-->í <!--[endif]-->Ambient temperature：-5 ~ +55∩ Ambient humidity：10% ~ 90%(non-condensing)
<!--[if !supportLists]-->í <!--[endif]-->Store temperature：-30 ~ +60∩ Store humidity：10% ~ 90%(non-condensing)
<!--[if !supportLists]-->í <!--[endif]-->Dimension: 185mm】122mm】33mm（L x W x H）
<!--[if !supportLists]-->í <!--[endif]-->Power:12V, 1A
<!--[if !supportLists]-->í <!--[endif]-->Power Consumption: ÷9W
<!--[if !supportLists]-->í <!--[endif]-->Weight（No Power Adapter）: About 350g
Parameter:
|
Parameter Name
|
Hardware Parameter
|
|
Main chip
|
Realtek
|
|
PON
|
EPON, SC symmetric 1.25Gbps
single-mode/single-fiber or double-fiber
|
|
PON Port Type
|
BOSA
|
|
Wavelength
|
Tx 1310nm, Rx 1490nm, CATV 1550nm
|
|
Sensitivity
|
<-27dBm(PX20+)
|
|
Overload
|
> -3dBm(PX20+)
|
|
Optical Type
|
SC/APC
|
|
LAN Interface
|
1*GE+1*FE
|
|
Auto adaptive Ethernet interfaces, Full/Half Duplex, RJ45 connector
|
|
RF (CATV)
|
1 CATV F connector
|
|
Parameter Name
|
Software Parameter
|
|
Internet connection
|
Bridge / Routing
|
|
LAN
|
Support Port rate limiting
Support Loop detection
Support Flow control
Support Storm control
|
|
VLAN
|
Support VLAN tag mode
Support VLAN transparent mode
Support VLAN trunk mode
Support VLAN translation mode
Support VLAN QinQ mode
|
|
Multicast
|
Support IGMPv1/v2/v3
Support IGMP Proxy and MLD Proxy
Support IGMP Snooping and MLD Snooping
|
|
L3
|
Support IPv4、IPv6 and IPv4/IPv6 dual stack
Support WAN DHCP/PPPOE/Static IP
Support Static Route
Support NAT
Support DMZ
Support Port forwarding
Support DHCP server
|
|
Security
|
Support Firewall
Support Mac filter
Support ACL
Support URL filter
|
|
QoS
|
Support 4 queues
Support SP and WRR
Support 802.1P
Support DSCP
|
|
CATV
|
RF Video Output Bandwidth (MHz):45~875
RF Output Level(dBuv):80
AGC Dynamic Range(dBm):-6~+2
|
|
Management
|
Support CTC OAM 2.0 and 2.1
Support TR069
Support WEB
Support TELNET
|
Application:
