Hardware Features
|
|
Business
Interface
|
Supply 8 PON Port
|
|
4SFP 10GE
slots for Uplink
|
|
10/100/1000M
auto-negotiable,RJ45:8pcs for Uplink
|
|
Management
Ports
|
Provide
10/100Base-T RJ45 out-band network management port
|
|
It can
manage the in-band network through any GE uplink port
Provide
local configuration port
|
|
Provide
1 CONSOLE port
|
|
Data
exchange
|
3
layer Ethernet switching, switching capacity 128Gbps, to ensure non-blocking
switching
|
|
LED Light
|
RUN、PW
instructions system running、power working status
|
|
PON1 to PON8 instructions 8 pcs PON port LINK and Active status
|
|
GE1 to GE8 instructions 8 pcs GE uplink’s LINK and Active status
|
|
XGE1 to XGE4 instructions 4 pcs
10GE uplink’s Link and Active status
|
|
Power
Supply
|
220VAC AC: 100V~240V,50/60Hz
DC:-36V~-72V
|
|
Power
Consumption 60W
|
|
Weight
|
4.5 Kg
|
|
Working
Temperature
|
0～55℃
|
|
Dimension
|
300.0mm(L)* 440.0mm(W)* 44.45mm(H)
|
|
EPON Function
|
|
EPON Standard
|
Comply with IEEE802.3ah,YD/T 1475-200 and CTC 2.0 、2.1 and 3.0
standard
|
|
Dynamic
bandwidth allocation
(DBA)
|
Support
fixed bandwidth, guaranteed bandwidth, maximum bandwidth, priority, etc. SLA
parameters;
|
|
Bandwidth
granularity 64Kbps
|
|
Security
Features
|
Support
PON line AES and triple churing encryption;
|
|
Support
ONU MAC address binding and filtering;
|
|
VLAN
|
Support
4095 VLAN additions, transparent transmission, conversion and deletion;
|
|
Support
4096 VLAN additions, transparent transmission, conversion and deletion;
|
|
Support
VLAN Stacking (QinQ)
|
|
MAC address learning
|
Support
32K MAC addresses;
|
|
Hardware-based
wire-speed MAC address learning;
|
|
Based
on port, VLAN, link aggregation MAC restrictions;
|
|
Spanning
Tree Protocol
|
Support
IEEE 802.1d (STP), 802.1w (RSTP) and MSTP Spanning Tree Protocol
|
|
Multicast
|
Support
IGMP Snooping and IGMP Proxy, support CTC controllable multicast;
|
|
Support
IGMP v1/v2 and v3
|
|
NTP
protocol
|
Support NTP
protocol
|
|
Quality
of Service(QoS)
|
Support 802.1p
priority queue scheduling;
|
|
Support SP, WRR or
SP + WRR scheduling algorithm;
|
|
Access
Control Lists
(ACL)
|
According
to the destination IP, source IP, destination MAC, source MAC, destination
protocol port number, source protocol port number, SVLAN, DSCP, TOS, Ethernet
frame type, IP precedence, IP packets carried protocol type ACL rules set;
|
|
Support
the use of the ACL rules for packet filtering;
|
|
Support
Cos ACL rule using the above settings, IP priority setting, mirroring, speed
limit and redirect the application;
|
|
Flow
Control
|
Support
IEEE 802.3x full-duplex flow control;
|
|
Support
port speed;
|
|
Link
Aggregation
|
Support
8 port aggregation group, each group supports 8 member ports
|
|
Port
Mirroring
|
Support
the port mirroring of uplink interfaces and PON port
|
|
Log
|
Support by the alarm log output level shield;
|
|
Support
for logging output to the terminal, files, and log server
|
|
Alarm
|
Support
four alarm levels (severity, major, minor, and warning);
|
|
Support
6 alarm types (communication, quality of service, processing error, hardware
equipment and the environment);
|
|
Support
alarm output to the terminal, log and SNMP network management server
|
|
Performance
Statistics
|
Performance
statistics sampling time 1 ~ 30s;
|
|
Support
the 15 minutes performance statistics of uplink interfaces ,PON port and ONU
user port
|
|
Administration maintenance
|
Support
OLT configuration save, support restore the factory settings;
|
|
Support
OLT online upgrade;
|
|
support ONU
offline service configuration and automatically configure ;
|
|
Support
ONU remote upgrade and batch upgrade;
|
|
Network
management
|
Support
local or remote CLI management configuration;
|
|
Support
SNMP v1/v2c network management, support band, in-band network management;
|
|
Support
the standard of broadcasting industry "EPON + EOC" SNMP MIB and
support auto-discovery protocol EoC headend (BCMP);
|
|
Support
WEB config mamagement
|
|
Open
interfaces for third-party network management;
|
