INFORMATION
General Description
GPON
ONU 1GE is a new GPON ONU production of Our Company which passive optical network terminal series. It provides one
10/100/1000Mbps base-T interface, one optical interface, and it is very impact.
Suitable for home and small
business users, can meet the FTTH
high-speed data transmission of the application.
Model: BD-ONU-111-Z-B
Key Features
n It
takes the PTMP (point to multipoint)network topology, effectively collects and
converges scattered Ethernet services, and provides the 10/100/1000M Ethernet
standard RJ45 interface, smoothly interconnects with existing networks.
n The
Dynamic Bandwidth Allocation (DBA) mechanism enables all users to share the
1Gbps bandwidth reasonably, guaranteeing a reliable QoS.
n Supports
IGMP multicast, effective use of broadband;
n Supports
multicast VLAN;
n Full
management through an Operation Administration Maintenance (OAM) protocol based
on IEEE802.3ah, including configuration, alarm, performance monitoring, fault
isolation and security management, etc. It supports remote management through
OLT and local console management as well.
n Supports
FEC and DBA;
n Supports IEEE802.1Q VLAN protocol;
n Supports IEEE 802.1p protocol;
n Supports remote loopback
and network status diagnosis；
n Supports flow statistics；
n Supports storm control;
n Support NAT;
n Support PPPOE;
n Support DHCP Server Client;
n Support Route;
Technical Parameter
|
Module
|
GPON ONU 1GE
|
|
User nterface
|
1 10/100/1000M RJ45
port.
|
|
PON
|
Transmission speed
:upstream/downstream symmetrical 1Gbps
Network coverage
radius: 20KM
Optical receive
sensitivity:≥-27dBm
Continuous light power: 0dBm~+4dBm
Security: SFU
authentication mechanism
|
|
Protocol
|
Compliant with IEEE 802.3ah
YD/T 1475-2006
IEEE 802.1D, Spanning Tree
IEEE 802.1Q, VLAN
IEEE 802.1w, RSTP
IEEE 802.3ad (LACP)
Ethernet–II, Ethernet-SNAP
|
|
Route
|
Support
NAT
Support
PPPOE
Support
Server Client
Support
Route
|
|
VLAN
|
Port-based
VLAN
GVRP
IEEE
802.1Q VLAN
|
|
QOS
|
Backpressure flow control(half-duplex)
IEEE 802.3x flow control(full-duplex)
Prevent Head Of Line
IEEE 802.1p, CoS
WR,SP and FIFO queue scheduling algorithm
Port rate limit
|
|
Safety
|
IEEE 802.1x,access control based upon Port; support
local and remote RADIUS.
CHAP,EAP certification;
Storm control, port protection,
|
|
Management
|
Various management modes such as Web, TELNET
Debug function.
|
|
Size
|
90mm(L)×80mm(W)×22mm(H)
|
|
Environment
|
Operating temperature:0℃～60℃;
Operating humidity:10%～85% non-condensing
|
|
Storage temperature:-40℃～80℃;
Storage humidity:5%～95% non-condensing
|
|
Power supply
|
110～240VAC 12V/0.5A
DC
power interface size:2.1mm/5.5mm
|
|
Power Consumption
|
2.5W
|
