INFORMATION
Description
1ch 3G-SDI with loopout Fiber Video Converter, 20KM,Tx/Rx.
System
Design
Fiber Optic Video Transmitter & Receiver
SDI
series can transmission 1-Channel
3G-SDI video over 1 single core
fiber.
Single-Mode
3G-SDI unit is designed to support
LC /PC Optical connector
We
will offer free patch cord + adaptor for your request for SC/PC or ST/PC or
FC/PC optical connector.
The
Transmission distance Range according to the Optical Budget.
Manufacturer's
default standard is single mode 20Km .
Features
•1 Channel Video of 3G-SDI can be transmitted via 1 single fiber
• The Max rate of work is 3.2Gb/s
• Support SMPTE 292M (2.9Gb/s) clock recovery
• Support standard of
1.485Gbps/M(HD-SDI/ SD-SDI),SMPTE 425M 3Gb/s Mapping(3G-SDI),SMPTE 424M 3Gb/s
serial interface(3G-SDI)
• Out wavelength range is 1310nm、1550nm and 16 other kind of CWDM
wavelength ( comply with ITU-T G.694.2)
• Automatic cable equalization ,used for all rate
below 3.2 Gb/s（Belden 1694A）
• LED Status Indication to monitor the working conditions
• Video transmission system
can support many application branches structure
•The fiber port Support SFP transceiver hot-plugged
•The SDI video format support：
625/25 PAL
525/29.97 NTSC
525/23.98 NTSC
720p50、720p59.94
1080P 23.98/24/30/50/60
1080i 23/24/30/50/59.94
Typical
application
Remark:
•The Optical Power Budget
fit Multi-mode(62.5/125m),Single-Mode(9/125 m).
•When using 50/125 m
multimode fiber, subtract 3 dB from the optical power budget.
•Optical transmission
distance is limited to optical loss of the fiber and any additional loss
introduced by connectors, splices and patch panels.
•Maximum transmission
distance is also limited by fiber bandwidth.
•Power adapter for stand-alone
units is manufactured by third party .Power adapter included US, European, UK
or Australian power plug.
•Please feel free to contact
factory for any special requirement and customization
Specifications
Video
Number of channels : 1 channel with loopout
Input/out put Connector : BNC 75Ω
Input/output voltage: 1.0 Volt p-p
Video Bits Rate: Max 3.2Gb/s
Video SDI Standards: 270Mbps(SD-SDI)
1.485Gbps/M(HD-SDI)
SMPTE425M3Gb/s Mapping(3G-SDI)
SMPTE424M
3Gb/s serial interface(3G-SDI)
Fiber
Optic
Number
of Optical port : 1 SFP
Connector
: Simplex LC
Transmission
Distance:Single-mode 20Km
Single-mode:1310/1550nm,1490nm (Option)
Connectors
Video
: BNC 75Ω
Fiber
Optical : Simplex LC
Stand-alone
power: DC JACK
Rack
power: AC line cord
Electrical & Mechanical
Power
adaptor : AC 100-240V to DC 5V 2A
Power
consumption : <3W
Environmental
Operating
Temperature : - 5C~+75 C
Storage
Temperature : - 5 C~+85 C
Relative
Humidity : 0%~95% (non-condensing)
MTBF
: >100,000 hours
Remark: To meet the needs of our customers and
help them to realize their projects, we also can manufacture the products
according to customers' requirements.
Ordering information
